Why this one
01
Cross line, five spots
Plumb, level and square points plus a cross line.
02
12V or 18V XR
Takes batteries from either DeWalt platform.
03
Fine-adjust knob
Rotates beams precisely onto a reference.
04
±3 mm accuracy
At 10 m, with green beam and 50 m detector range.
The story
Floor to ceiling in seconds
Electricians, sprinkler fitters and ceiling installers constantly transfer points from floor to ceiling for fixings, downlights and hangers. The DCE825 projects up and down plumb spots plus level and square spots, together with a cross line, so points and lines can be marked from one setup.
Fine control
A fine-adjustment knob rotates the beams precisely onto a reference mark, which saves nudging the whole unit. The green diode is easy to see indoors, with 30 m working range and 50 m with a detector in pulse mode. Accuracy is ±3 mm at 10 m, and the pendulum locks for transport.
Runs on 12V or 18V
The multi-voltage battery holder takes both 12V and 18V XR packs, so it can share batteries with nearly any DeWalt cordless tool. The housing is IP54 rated. The bare unit comes with a TSTAK-compatible case, laser target and wall mounting bracket.
Specifications
Measuring & detection
- Beam colourEF019151
- Green
- Laser lines
- 2
- Working rangeEF014226
- 30m
- Working range with receiverEF019450
- 50m
- Accuracy
- 3mm/10 m
- BluetoothEF007699
- — No
- Receiver included
- — No
