Why this one
01
1,000 Nm nut-busting
Breaks seized nuts; 700 Nm maximum fastening torque.
02
Auto-stop modes
Three reaction-time settings stop the wrench when the nut seats.
03
XPT protection
Seals against dust and water for outdoor steelwork.
04
M10–M24 capacity
Standard bolts on a 1/2" square drive.
The story
Built for bolted work
Steel erectors, scaffold and plant crews and groundworkers need to run bolts up and break them loose without a compressor. The DTW700 covers M10 to M24 standard bolts on a 1/2" square drive, enough for steel connections, formwork, anchor bolts and vehicle wheel nuts.
Four modes and auto-stop
Four power settings run from 150 Nm to 700 Nm, and three reaction-time settings stop the tool automatically once the nut seats, in forward or reverse. That limits over-tightening and stops loosened nuts spinning off the thread. XPT sealing, a job light and an ergonomic chassis make it suitable for outdoor work.
In the LXT range
At 2.0 kg bare it is compact for its output and runs on the same LXT packs as your drills and drivers, so there is no extra platform to carry. An extension handle and a Type 3 MAKPAC with inlay are listed as options.
Specifications
Drilling & driving
- Torque, hard jointEF002842
- 700Nm
- Breakaway torque
- 1,000Nm
- No-load speed, gear 1EF011125
- 2,2001/min
- Impact rateEF004984
- 2,7001/min
- Tool holderEF002843
- ½″ square drive
- Max. screw diameterEF005261
- 24mm
