Why this one
01
2.5 J impact energy
Optimised for anchor holes from 6 to 20 mm in concrete.
02
FIXTEC chuck change
Swap SDS-plus for a 13 mm metal chuck in seconds.
03
AUTOSTOP protection
Stops the motor if the bit snags rebar.
04
ONE-KEY tracking
Location, inventory and remote lock-out in the free app.
The story
For fixing into concrete
Electricians, plumbers and M&E installers drilling anchors, containment fixings and cable holes in concrete spend most of their time in the 6 to 20 mm range. This hammer is optimised for that work, with 2.5 J of impact energy and capacity up to 26 mm in concrete.
Safety and versatility
AUTOSTOP detects the body spinning when a bit snags rebar and stops the motor. Four modes cover rotary hammering, chiselling, drilling without hammer and chisel positioning. The FIXTEC system swaps the SDS-plus holder for a 13 mm metal chuck, so the same tool drills steel and timber.
System and dust control
The tool accepts the M18 FCDDEXL and FDDEXL dust extractor attachments for overhead drilling, and ONE-KEY adds tracking and remote lock-out. It runs on all M18 packs; the kit ships with two HIGH OUTPUT 5.5 Ah batteries, an M12-18 FC charger and an HD Box.
Specifications
Concrete & demolition
- Impact energyEF002831
- 2.5J
- Impact rateEF004984
- 4,8001/min
- No-load speedEF008590
- 1,3301/min
- Tool holderEF002843
- SDS-plus
- Optimal drilling range, up to
- 20mm
- Max. drilling diameter, concreteEF004553
- 26mm
