DeWalt DWS780 305 mm Slide Mitre Saw with XPS
Benchmark 230 V 305 mm double-bevel slide mitre saw
- 305mm
- 110mm
- 25.5kg
In the box
- 1×305 mm 60-tooth blade
- 1×Blade wrench
- 1×Dust bag
- 1×Material clamp
A corded 1675 W, 305 mm slide mitre saw with variable speed, 303 × 110 mm crosscut capacity and double bevel to 49°. The XPS LED shadow line and stainless detent plate make repeat cuts quick and accurate.
Why this one
01
303 mm crosscut
110 mm deep at 90° for boards, frames and skirting.
02
XPS shadow line
Exact cut line with no laser to calibrate.
03
Double bevel 49°
Cut compound mitres without flipping the workpiece.
04
Variable speed
1,900–3,800 rpm for wood, plastics and aluminium.
The story
The joinery shop standard
The DWS780 has been a fixture in joinery shops and on shopfitting jobs for years. It crosscuts 303 mm wide at 110 mm deep, has 170 mm vertical capacity against the fence for tall skirting, and bevels 49° both ways, which covers almost any trim, frame or architrave profile without flipping the workpiece.
Accuracy you can repeat
A machined base and a stainless steel mitre detent plate with ten common stops make settings easy to return to. The XPS LED projects the blade's shadow onto the workpiece, so the cut line is exact without calibrating a laser. Variable speed from 1,900 to 3,800 rpm helps with plastics and aluminium profiles.
Mains saw for the workshop and site
The 230 V -QS version is the Nordic and European model. It comes with a 60-tooth blade, dust bag, clamp and wrench, and the dust port takes an extractor hose for cleaner indoor cutting. For cable-free sites, the FLEXVOLT DCS781 offers similar capacity.
Specifications
Sawing
- Blade diameterEF002855
- 305mm
- ArborEF002856
- 30mm
- Cutting depth at 90°EF002849
- 110mm
- Cutting depth at 45°EF002850
- 63mm
- Max. bevel angleEF004988
- 49°
- Max. mitre angle
- 60°
- Max. cutting widthEF008599
- 303mm
- No-load speedEF008538
- 3,8001/min
- Guide rail compatible
- — No
- Blade brake
- — No
- Scoring blade
- — No
- Dust extraction port
- ✓ Yes
Power
- Power sourceEF000145
- Corded (mains)
- VoltageEF000002
- 230V
- Motor
- Brushed
- Rated inputEF001950
- 1,675W
Physical
- WeightEF011121
- 25.5kg
- LengthEF001438
- 770mm
- WidthEF000008
- 470mm
- HeightEF000040
- 396mm
- LED work light
- — No
- Belt hook
- — No
